Floating Granite Sphere at CU Boulder | Flow Visualization | Get Wet Assignment 1 | 2024

This video showcases the iconic floating granite sphere situated in the courtyard of the Engineering Center in front of the DLC building at the University of Colorado Boulder. Captured and edited by Dron Das Purkayastha as part of an assignment for the Flow Visualization class (MCEN 5151) at the Paul M. Rady Department of Mechanical Engineering, University of Colorado Boulder.

The video was shot using a Canon M50 Mark I paired with a Canon EF 50mm STM prime lens. Filmed at 120 FPS in 720p (8-bit), the slow-motion footage highlights the sphere’s intricate motion and flow patterns. The horizontal width of the sphere in the frame measures 10 cm.

Aperture F10
Shutter !/160
ISO 200

Video link https://vimeo.com/1008666657

Dyed water injected into dyed corn syrup displays the Saffman-Taylor fingering instability in a Hele-Shaw cell.

Dyed water injected into dyed corn syrup displays the Saffman-Taylor fingering instability in a Hele-Shaw cell.

Dyed water and air injected into honey produces the Taylor-Saffman instability in a Hele-Shaw cell.

Dyed water was injected into Dawn dish soap to make the Saffman-Taylor fingering instability in a Hele-Shaw cell, and then the top plate was raised and lowered to add air bubbles.

Bénard-Marangoni convection instability occurs as horizontal layer of silicone oil with aluminum flakes is heated from the bottom with a free surface on top. Variations in temperature cause surface tension gradients that drive the flow.

Aluminum flakes in a pool of silicone oil heated from below displays the Bénard-Marangoni convection instability. Here is a time lapse taken over the period of two minutes.

Aluminum flakes in a pool of silicone oil heated from below displays the Bénard-Marangoni convection instability.

Aluminum flakes in a pool of silicone oil heated from below displays the Bénard-Marangoni convection instability. The resemblance to the Sun was achieved with post-processing of color.

Water droplets at the center of a heated pan exhibit the Leidenfrost effect, where film boiling insulates the droplet. Away from the hottest center, droplets evaporate quickly.

Water droplets at the center of a heated pan exhibit the Leidenfrost effect, where film boiling insulates the droplet. Away from the hottest center, droplets evaporate quickly.
